Siemens 6ES7315-2EH13-0AB0 Central Processor Unit

Siemens 6ES7315-2EH13-0AB0

Siemens 6ES7315-2EH13-0AB0

Siemens 6ES7315-2EH13-0AB0

Packaging Dimension 13,10 x 15,30 x 5,20cm

lead time : 3 working days

Main products: DCS distributed control system, PLC programmable controller, numerical control system, (CPU processor, module, card, controller, servo drive, workstation, driver, motor, memory card, power supply, robot spare parts, etc.) Various industrial control products

Contact detail:

Mobile/ WeChat/ WhatsApp:+86-17354319552

E-mail:sophia@swanautomation.com

Skype: sophia_9090@163.com

QQ: 2747366625

Contact:   Sophia

Shipping & Payment:

1.Shipping will be made via DHL,TNT,EMS,FedEx or USP .
If you would like to use your shipping account number please contact us with that information.
2.We ship within 3-5 working days after receiving payment from the buyer.
3. All the goods will be tested before shipment ,we will track the goods until you received.
4.Payment: T/T
5.New original with one year warranty.

6.MOQ:1pcs

Feedback:
We want our customers to be completely satisfied with their purchase. If anything about your transaction is not your satisfaction. Please contact us before leaving Feedback. It gives both the parties the chance to get positive trading experience in future.

S7-300 PLC is an analog small to medium-sized PLC, with independent power supply, CPU, and other modules. The power supply (PS), CPU, and other modules can be tightly fixed on the standard track of Siemens S7-300 through a U-shaped bus. Each module has a bus connector, which is plugged into the back of each module. The power module is always installed on the far left side of the rack, with the CPU module next to the power module. On the right side of the CPU is the IM interface module that can be selected. If only the main rack rail is used and no expansion bracket is used, the IM interface module can be omitted.

When configuring the hardware of the main rack rail using S7 programming software, the power supply, CPU, and IM are placed in slots 1, 2, and 3 of the rail, respectively. A guide rail has a total of 11 slot numbers: slot 1 to slot 11, where slots 4 to 11 allow for the placement of modules other than power, CPU, and IM at will. For example, DI (digital input), DO (digital output), AI (analog input), AO (analog output), FM (functional module), and CP (communication module).

2.3.2 S7-300 CPU module

The CPU module is the core of the control system, responsible for the central control responsibility of the system, storing and executing programs, achieving communication functions, and increasing 5V power supply for the U-shaped bus.

The CPU has four operating modes: STOP, STARTUP, RUN, and HOLD. In all modes, communication with other devices can be achieved through the MPI interface.

The CPU modules of S7-300 can be roughly divided into the following categories:

1. 6 types of compact CPUs with integrated functionality and I/O: CPU 312C, 313C, 313C-PtP, 313C-2DP, 314C-PtP, and 314C-2DP.

2. Innovative standard CPU: CPU 312, 314, and 315-2DP.

3. 5 standard CPU: CPU 313, 314, 315, 315-2DP, and 316-2DP.

4. Outdoor CPU: CPU 312 IFM, 314 IFM, 314 Outdoor, and 315-2DP.

5. High capacity high-end CPU: 317-2DP and CPU 318-2DP.

6. Master slave interface secure CPU: CPU 315F-2DP
