GE Fanuc IC694MDL660 Input Module

IC694MDL660

IC694MDL660

IC694MDL660

If you need to inquire or purchase ,please send the product models to my email or call me directly .

Shipping & Payment:

1.Shipping will be made via DHL,TNT,EMS,FedEx or USP .
If you would like to use your shipping account number please contact us with that information.
2.We Ship after receiving payment from the buyer.
3. All the goods will be tested before shipment ,we will track the goods until you received.
4.Payment: T/T Western Union

5.New original with one year warranty

Feedback:
We want our customers to be completely satisfied with their purchase. If anything about your transaction is not your satisfaction. Please contact us before leaving Feedback. It gives both the parties the chance to get positive trading experience in future.

Sales of the brand:

1.BENTLY NEVADA Bentley 3500 monitoring system: 3500/22M 3500/53 3500/45 3500/15 3500/25 3500/20 3500/42M 3500/33 3500/32 3500/50 3500/50M

2.Schneider/Modicon （140CPU67160,140CPU43412A,AS-BADU-205,....）

3.Siemens:(6DD,S-200,S-300,S-400,S-1500,S5,S-1200,SIMADYND,Siemens Moore,VIPA PLC ...)

4.GE (General Electric): IC693/IC697/IC698/IS200/DS200/IS215 modules, cards, drivers and other spare parts.

5.ABB S800 module AI810/CI830/DI810/DO810/AO810/DO820/DI821/TU831V1 DCS system AC800F controller EI803F.FI830F.FI810F.PM856K01.PM802F.PM802F.PM825.

6.InvensysTriconex: 3700A/3805E/4351B/3503E/3625/3008/4119A/8312/3703E/3511/redundant fault-tolerant control system, the most modern fault-tolerant controller based on triple modular redundancy (TMR) structure

7.Rockwell AB 1756.1747.1746.1769 1794 1771 1785 series PLC module

8.Foxboro FCP270 FB201 FBM202 FBM204 FBM237 FBM242 FBMSVH FBMSSW module, matching terminal cable

9.Westinghouse Ovation system | Westinghouse Emerson DCS process control conditions

10. YOKOGAWA (CP345,CP451-10,AMM12C,AAI141-S00...)

11.FOXBORO (FCP270,FBM217,FBMSVH，FBMSSW，FBM213...)

12. BACHMANN (MPC240,CM202,DI232,MPC240,NT255,AIO288...)

13.Honeywell（CC-PAIH02,FC-SAI-1620M，MC-TAOY22，CC-PDOB01,CC-PAOH01 51405039-175 .

14.Emerson Ovation (1C31194G01,1C31197G01,5X00106G01,1C31125G02...)

Common models:

Input Module, 24 VDC 32 Point Grouped: IC694MDL660

 The 24 VDC Positive/Negative Logic Input module, IC694MDL660,
provides 32 discrete input points. The inputs are positive or negative
logic inputs and will operate at levels up to 30V.
The inputs are arranged in four isolated groups of eight; each group
has its own common. Isolation is provided between the four groups
of inputs, however each group of eight inputs is referenced to the
same user common connection.
Module MDL660 provides seven selectable input filter times. Filter
times can be set from the programmer using the module’s assigned
output data references.
This module can be used with either a Box-style (IC694TBB032) or
Spring-style (IC694TBS032) front Terminal Block. The Terminal
Block is ordered separately.
32 green LEDs indicate the ON/OFF status of points 1 through 32.
The red/green TB LED is green when the module’s removable
terminal block is locked in place. It is red when the terminal block is
not locked. The module also sends an Addition of Terminal Block or
Loss of Terminal Block message to the RX3i CPU to report the
terminal block status.
The blue bands on the label show that MDL660 is a low-voltage
module.
This module can be installed in any I/O slot in an RX3i system. It
must be used with an RX3i CPU (release 2.90 or later). It cannot be
used with a Series 90-30 PLC CPU.
Module MDL660 uses 48 input bits and 16 output bits to exchange
point status and filter information with the RX3i CPU.
