View MoreAllen Bradley 20F11NC030AA0NNNNN PowerFlex 753 Frequency AC drive The 20F11NC030AA0NNNNN built by Allen Bradley (AB) is a 15 kW module. This VAC drive includes optional communication slot built-in, is a 400VAC/540V DC VFD, and has an IP20/IP00 (NEMA UL Type Open) enclosure type. Also, it has an amperage output rating of 30 Amp. Furthermore, it comes with a dynamic brake included in the VFD in case braking is required. Additionally, this Rockwell Automation frequency drive has no HIM unit included, instead the drive comes with a plastic cover.
View MoreAllen Bradley 20F11NC022JA0NNNNN PowerFlex 753 Frequency AC drive The Allen-Bradley 20F11NC022AA0NNNNN drive is an air-cooled drive with an open enclosure. It is part of the PowerFlex 753 drive series. The 20F11NC022AA0NNNNN operates with 400 Volts AC and 540 Volts DC voltage.
View MoreAllen Bradley 20F11NC022AA0NNNNN PowerFlex 753 Frequency AC drive The Allen-Bradley 20F11NC022AA0NNNNN drive is an air-cooled drive with an open enclosure. It is part of the PowerFlex 753 drive series. The 20F11NC022AA0NNNNN operates with 400 Volts AC and 540 Volts DC voltage.
View MoreAllen Bradley 20F11NC015JA0NNNNN PowerFlex 753 Frequency AC drive The Allen-Bradley 20F11NC015AA0NNNNN drive is a PowerFlex 753 series drive. It is rated for 400 Volts AC or 540 Volts DC nominal voltage. It has an operating current rating of 15.4 Amps.
View More
Allen-Bradley 1766-L32BXBA AB CPU Module
This Allen-Bradley MicroLogix 1400 has (12) Digital Fast 24V DC, (8) Digital 24V DC, (4) Analog Inputs and (6) Relay, (3) Fast 24V DC, (3) Normal 24V DC, and (2) Analog Outputs. This MicroLogix Module has a built in LCD display, RS-232, and Etherent Port.
Item NO.:
1766-L32BXBAOrder(MOQ):
1Payment:
T/TProduct Origin:
USAColor:
WhiteShipping Port:
HKLead Time：
3 days after payment
1、 Basic parameters and functions
Model: 1766-L32BXBA
Brand: Allen Bradley (Rockwell Automation)
Product Type: MicroLogix 1400 Controller
Power supply method: Powered by an external 24VDC power source
Input/output characteristics:
Built in 12 fast 24VDC input points
Built in 8 standard 24VDC input points
6 relay outputs
3 fast DC outputs
3 standard DC outputs
2 voltage input channels
2 voltage output channels
2、 Communication interface
Isolation RS232/RS485 combination port: 1 port
Non isolated RS232 communication port: 1
Ethernet communication port: 1
3、 Programming and software support
Programming software: RSLogix 500
4、 Product Features and Applications
High performance: The MicroLogix 1400 series controllers are designed to expand their application range, with faster processing speeds and richer features.
Flexibility: Supports multiple input/output configurations and communication protocols to meet the needs of different industrial applications.
Usability: With RSLogix 500 programming software, users can easily develop programs and configure systems.
Scalability: A single MicroLogix 1400 controller can expand up to 7 1762 input/output modules to meet the needs of more input/output points
Technical Specifications
|
Manufacturer |
Rockwell Automation |
|
Brand |
Allen-Bradley |
|
Series |
MicroLogix |
|
Part Number |
1766-L32BXBA |
|
Product Type |
Power supply |
|
Size |
20 x 20 x 15cm |
|
Weight |
0.5 KG |
|
Quality |
100% New Original |
|
Stock |
In stock |
|
Delivery time |
1-3 days after Payment |
|
After-sales Service |
Have |
|
Warranty |
1 year |
|
Shipping term |
DHL / FEDEX/ EMS /UPS/TNT/EMS |
